Insulation Resistance Tester Meter Megohmmeter Insulation Resistance Measurement Instrument with Insulation Resistance Range 0.1MΩ to 200GΩ 4-Digit Large LCD Display

YFYIQI Insulation Resistance Tester Meter Megohmmeter Insulation Resistance Measurement Instrument with Insulation Resistance Range 0.1MΩ To 200GΩ 4-digit Large LCD DisplaySpecification:❤Function: Insulation resistance test, AC voltage test, DC voltage test❤Power supply: DC 1.5V 6 LR14 dry batteries for more than 100 hours of continuous standby（Batteries are not included durring the shipping）❤Rated voltage: 50V / 250V / 500V / 1000V / 2500V ❤Insulation resistance range: 0.1MΩ～200GΩ❤Voltage range: AC/DC 0V～750V ❤Output short-circuit current: ≥2mA❤Maximum capacitive load: 1uF ❤Shifting: Turn the shift knob to select the corresponding gear ❤Backlight: Controllable off-white backlight, suitable for use in dark places ❤Display mode: 4-digit large LCD display, obvious contrast ❤Measurement indication: LED flashes during measurement, buzzer sounds ❤LCD size: 108mm×65mm ❤Instrument size: length, width and height: 212mm×175mm×76mm❤Test line: high-pressure bar test line: 1 red; test lead test line: 1 black; crocodile clip test line: 1; crocodile clip: 1 ❤Measurement time: The single test time is 1min. During the test, the user can manually stop or automatically stop after 1min, and the screen displays the measurement data.❤Battery voltage: The battery under-voltage symbol displays. When the battery voltage is low, it reminds to replace the battery in time. ❤Automatic discharge function: The symbol flashes during discharge; the symbol after discharge is extinguished. ❤Auto power off function: Auto power off after 15 minutes of power on ❤Power consumption: Standby: about 40mA (backlight off); Measurement: about 100mA (backlight off) Accessory:❤Meter ❤High pressure bar❤Pen test line❤Crocodile clip test line❤alligator clip❤Manual❤Certificate❤Warranty Card

• 1. Max output voltage 5000V, Max test resistance 400GΩ, Max short circuit current 2mA
• 2. Insulation resistance value, test time and output voltage are displayed on the same screen.
• 3. Safe structure and improved circuit new design, more complete function, higher accuracy, more convenient and reliable operation.
• 4. Perfect protection circuit, which can effectively prevent the damage of counter voltage.
• 5. The host with large LCD display, white screen and backlight, bar chart indication, clear and obvious.
