Lab Colorimeter Precise Color Meter With Measure Caliber 8MM 20000 Groups Data Storage Free Color Software Repeatability △E﹡ab≤ 0.06 Silicon Photodiode Array Sensor SCI SCE Synchronous Test Mode

Introduction This high precision colorimeter is developed and produced according to the international standard of CIE and GB. By adopting the latest 8/d optical configuration and equipped with sensor of high sensitivity. It has a high reproducibility and stability. Technical Specifications Optical geometry: 8/d, equipped with SCI and SCE Synchronous test mode Measure caliber: 8MM Observer: 2°& 10° Sensor: Silicon photodiode array System language: Simplified Chinese,Traditional Chinese, English Repeatability: Standard deviation △E﹡ab≤ 0.06( Using the standard whiteboard to measure 30 times and take the average.) Display: Value of chromatism, chromatic value, color space figure, qualified/ unqualified determination color analysis Observing light source: D65 D50 C A F2 F8 F11 Color space figure: L* a* b、L* c* h、Yxy、RGB Color difference formula:△E* ab、△E* ch Power source: Special 3200 mAh large-capacity lithium battery, AC adapter Data storage: 20000 groups Dimension: 196×71×93(L×W× H) Weight: 660g(including the calibration boards) Connection: USB Scope of application Color matching in industry and quality control in production process. Color-difference detection and color-difference bath control in production process. Color-difference analysis of spray paint surface and electroplate surface. Color-difference of different areas of the metal treating surface. Quality control in color difference in sample and the standard. Color difference inspection of batch products in outdoors. On-line monitoring of color difference in production process. Color analysis testing in other special industry etc.

• ◆(1)By adopting the latest 8/d optical configuration and equipped with sensor of high sensitivity. It has a high reproducibility and stability.
• ◆(2)Comply with the international general color detection standard which will ful- fill the demand of different industries.
• ◆(3)3200mAh Li-battery with large capacity ensures more convenient and reliable operation for long time measurement.
• ◆(4)Adopting Germany high sensitivity sensor and light source with high diffuse reflection coating integrating sphere structure above 96% ,which ensures m- ore precise measurement data.
• ◆(5)Equipped computer software can realize more detailed color data communication.
